SEMI Digital PA system
Semi Digital PA system adds control and communication function to the essential equipment of existing analog privilege of broadcasting, which realizes school broadcasting’s multi-function. According to social trend, we developed it by compensating equipment control and operation condition monitoring as PC management program for building requesting integrated operation. In the case that there is not PC program, you can conveniently use it by initial setup value.
|
|
 |
|
|
|
|
 |
|
| SPECIFICATIONS |
|
| Signaling Speed/Type |
9600bps/RS-232 |
| Input Channel |
6CH |
| Output Channel |
6CH |
| Display |
LED |
| Multi-zones Channels |
6 zones |
| Power Supply |
DC 24V |
| Weight |
4.8kg |
| Dimension |
482(W)×88(H)×378(D)mm |
|
| Main Feature |
|
| In case of fire alarm, automatically makes emergency announcement. |
|
- 6 multi-zones broadcasting for remote-broadcasting and announcement.
- Available for priority broadcasting according to each input source.
- remote amplifier control.
- Emergency broadcasting by data or contact closure.
- at fire, both visual and audio warning.
- 4 Multi zone system of Remote Amp.
|
|
 |
|
| Other.. |
|
|
|
