SEMI Digital PA system
Semi Digital PA system adds control and communication function to the essential equipment of existing analog privilege of broadcasting, which realizes school broadcasting’s multi-function. According to social trend, we developed it by compensating equipment control and operation condition monitoring as PC management program for building requesting integrated operation. In the case that there is not PC program, you can conveniently use it by initial setup value.
|
|
 |
|
|
|
|
 |
|
| SPECIFICATIONS |
|
| Input Channel |
Mono 8CH, Stereo 2CH |
| Output Channel 4CH |
4CH |
| S/N Ratio |
80dB |
| T.H.D |
0.5% and below |
| Frequency Characteristic |
30Hz~18kHz |
| Input Sensitivity |
Mic:-50dBm(balanced) |
| Line:-20dBm(unbalanced) |
| Weight |
6kg |
| Dimension |
482(W)×177(H)×200(D)mm |
|
| Main Feature |
|
| Digital Mixer for SEMI Digital PA SYstem which can be controlled via PC |
|
- 10 input / 4 output.
- Available for source devices control with Digi Link.
- Phantom power for each input channel.
- Possible to double extend input channel with two MX2412.
- Output selection of input channels, output volume, 3Band EQ, output meter and power on/off memory control are allowed by management program.
|
|
 |
|
